The
Saragosa SW has built an incredible reputation and the newly released 2020
model takes it to the next level with unmathced durability.
Packed with upgrades to deliver great cranking power and
unmatched durability, no other reel compares at this price point. The Saragosa
SWA series features 8 models with the 14000XG and 18000HG being new additions
for 2020. Top tier Shimano technologies such as X-Protect, X-Ship, Hagane Body
and Hagane gear are built into its lightweight compact body. With reduced
weight across the entire Saragosa SW series, the reel’s handling and balance
are further elevated. Modeled after the Stella SWC, the built-in InfinityDrive
improves pinion gear support, allowing greater and smoother cranking power. The
X-Protect water resistance system improves the line roller durability to an
IPX8 standard. Built for big fish in extreme conditions, the Saragosa SWA
continues to push the boundaries with its Unmatched Durability.
PRODUCT TECHNOLOGIES
· HAGANE
HAGANE is a Shimano reel design
concept created to withstand continual use and extreme abuse. HAGANE is an
innovation with built-in toughness and durability that works alongside
Shimano's precision engineering. HAGANE is for all anglers.
· HAGANE GEAR
With amazing
strength and durability, the HAGANE Gear is at the very heart of most Shimano
reels. Shimano, through the application of state-of-the-art technologies, gives
anglers the long-lasting smoothness and enjoyment that is felt when anglers
first use a reel, over and over again. No cutting work is applied to the teeth
of the drive gear during fabrication; instead, the entire surface is calculated
in minute detail by a special 3D design and then formed by Shimano's
cold-forging technology. The result is assured resilience. HAGANE Gear is the
result of Shimano's endless pursuit for durability — this strength and power of
forged metal continue to represent the fundamental concept of Shimano reels.
· INFINITYDRIVE
INFINITYDRIVE is a
new main shaft supporting structure that improves winding torque and allows for
incredibly smooth and light rotation.
· X SHIP
X SHIP provides
improved gear performance. Large diameter drive gear, optimally positioned
pinion gear and drive gear, and two points bearings supported pinion gear
produce light reeling under load.
*Excluding 500
· X PROTECT
For medium and
small general-purpose spinning reels, which require lighter spinning, we
focused on a non-contact structure that does not compromise the lightness of
the spinning. In addition to conventional water-repellent treatment, a
labyrinth structure that suppresses water penetration is combined to achieve
high water-resistant performance despite the non-contact nature of the
structure. It is used in the stopper bearing section and line roller section.
Large reels for saltwater, a contact-type water-resistant structure is used for
large spinning reels that require higher water-resistant performance. By
physically cutting off the entry path of seawater with a low-sliding seal
member, high water-resistant performance is achieved while suppressing
rotational resistance. The stopper bearing and line roller parts are adopted,
and the stopper bearing part in particular achieves a water-resistant rating
equivalent to IPX8.
· X TOUGH DRAG
Each washer is made
of only metal and carbon to support the spool from both the top and bottom.
Smooth and stable drag performance has been refined by improving heat
resistance and durability.
· X SHIELD
The body is
water-resistant equivalent to IPX8 by water-resistant seals on the body, side
covers, and other parts of the body.
· CROSS CARBON DRAG
The CROSS CARBON
DRAG provides the smooth drag release and the durability.
· AR-C SPOOL
The spool has a
special spool ring shape. This creates a rectifying effect on the line and
realizes both suppression of line trouble and long casting performance.
· SA-RB
S A-RB bearings are
put through the same process as Shimano’s A-RB bearings but feature shields on
both sides of the bearings. These shields reduce the possibility of salt or
sand inhibiting the rotation of the bearing.
· ONE-PIECE BAIL
ONE-PIECE
BAILallows the line to travel unimpeded to the line roller. The seamless design
reduces friction and decreases the chance of tangles or the line catching on
the bail arm.
· HAGANE BODY
The use of
lightweight and rigid metals such as aluminum and magnesium firmly suppresses
deflection, distortion, and torsion of the reel. This protects delicate gear
meshing and enables smooth reeling.
· SALT WATER OK
Models that can be
used in saltwater
ITEM CODE
| MONO LINE CAPACITY (#TEST/YD)
| WEIGHT (OZ)
| BEARINGS
| GEAR RATIO
| RETRIEVE PER CRANK (IN)
| POWERPRO BRAID (LB/YDS)
| MAX DRAG (LB)
|
SRG6000SWAHG
| 12/265, 16/170, 20/120
| 16
| 5+1
| 5.7:1
| 41
| 30/295, 50/195, 65/140
| 22
|
SRG14000SWAXG
| 16/360, 20/260, 25/190
| 24.7
| 5+1
| 6.2:1
| 53
| 50/400, 65/315, 80/240
| 33
|
